REMACLEAN HM-U2
U-Series – for belt return side applications
This system is suitable for cleaning the conveyor belt in
the return side of the belt for speeds up to 6.5 m/s. The
carbide blade of the REMACLEAN HM-U2 allows an
effective cleaning. The designof the carbide blade with
its anti-caking coating guarantees extended service
life and high reliability. Precise pre-tensioning and
subsequent control is ensured thanks to the spindletype tension unit and an integrated scale.
Ապրանքի մանրամասն
Benefits
• High cleaning efficiency due to
optimal contact of the tungsten
carbide blade
• Long service life due to the use of
highly wear-resistant carbide
• Protection of the carrier body due
to run-off aprons at the segments
• Easy to fit and adjust
• Low maintenance
| Technical Data | ||||
| Conveyor Belt Width | Weight | A | B | C |
| [mm] | [kg] | [mm] | [mm] | [mm] |
| 500 | 34,1 | 480 | 720-1315 | 1500 |
| 650 | 35,8 | 600 | 840-11465 | 1650 |
| 800 | 48,1 | 720 | 960-1500 | 1700 |
| 1000 | 52,1 | 960 | 1200-1750 | 2000 |
| 1200 | 86,8 | 1080 | 1330-2370 | 2700 |
| 1400 | 91,2 | 1200 | 1450-2570 | 2900 |
| 1600 | 152,9 | 1440 | 1700-2696 | 3100 |
| 1800 | 162,9 | 1680 | 1900-2896 | 3300 |
| 2000 | 182,7 | 1800 | 2100-2896 | 3500 |
| 2200 | 185,5 | 2040 | 2300-3146 | 3750 |
| 2400 | 194,3 | 2280 | 2500-3396 | 4000 |
| 2600 | 205 | 2520 | 2700-3596 | 4200 |
